CAT6A Cable, 305m, Pull Box with Reel, Blue

CAB-CAT6AL-305
AVAILABLE TO ORDER
CAT6A Cable, 305m, Pull Box with Reel, Blue
Warehouse Status
Seven Hills - NSW
AVAILABLE TO ORDER
Loganholme - QLD
AVAILABLE TO ORDER
Tulla Central Warehouse- VIC
AVAILABLE TO ORDER
Mulgrave - VIC
AVAILABLE TO ORDER
Balcatta - WA
AVAILABLE TO ORDER

The CAB-CAT6AL-305 is a Cat6A U/UTP cable consists of 4 x copper conductor twisted pairs separated by a pair divider for superior AXT performance, LSZH jacket and a strength member for improved pulling tension. It supports data transmission speeds of up to 10 gigabits per second (10 Gbps).

  • Cable Type: UTP
  • Jacket Material: LSZH
  • Conductor Material: Bare Copper Cable
  • Insulation Material: HDPE
  • Cable Length: 305m
  • Cable Weight: 15.2kg/305m
  • Cable Diameter: 0.57
  • Cable Gauge: 23AWG
  • Jacket Thickness: 0.70 plus or minus 0.05mm
  • DC Resistance Unbalanced (Max.): in pair less than or equal 2.0%, pair to pair less than or equal 4.0%
  • DC Resistance (Max.): less than or equal 9.38 Omega/100m
  • Dielectric Strength (Max.): DC 1000V 1min No Breakdown
  • Mutual Capacitance at Frequency: less than or equal 5.8nF/100m
  • NVP: 69%
  • Operating Frequency: 500MHz
  • Flame Test Method: IEC60332-1-2
  • Installation Temperature: -20 ~ +60 degrees Celsius
  • Operating Temperature: -40 ~ +75 degrees Celsius
  • Packaging: Reel in Box

  • 305m Cat6A U/UTP reel in a box 500 MHz
  • 100% bare copper cable
  • 23AWGx4P
  • LSZH Jacket
  • Integrated pair separator
  • Internal strength member
  • ROHS, RCM and REACH compliant
  • GECA Claim Authenticated (PVC free)
