CAT6A Shielded Cable, 305m, Pull Box with Reel, Blue

CAB-SCAT6A-305
AVAILABLE TO ORDER
CAT6A Shielded Cable, 305m, Pull Box with Reel, Blue
Warehouse Status
Seven Hills - NSW
AVAILABLE TO ORDER
Fyshwick - ACT
AVAILABLE TO ORDER
Loganholme - QLD
AVAILABLE TO ORDER
Tulla Central Warehouse- VIC
AVAILABLE TO ORDER
Mulgrave - VIC
AVAILABLE TO ORDER
Balcatta - WA
AVAILABLE TO ORDER

The CAB-SCAT6A-305 is a high-performance Cat6A S/FTP network cable designed for indoor installations requiring enhanced safety and speed. This cable is perfect for high-speed data networks in commercial and residential settings where low emissions and high performance are essential.

  • Cable Type: S/FTP
  • Jacket Material: LSZH
  • Conductor Material: Bare Copper Cable
  • Insulation Material: Skin Foam Skin PE
  • Cable Length: 305m
  • Cable Weight: 16.8kg/305m
  • Cable Diameter: 0.56
  • Cable Gauge: 23AWG
  • Jacket Thickness: 0.55 plus or minus 0.05mm
  • DC Resistance Unbalanced (Max.): in pair less than or equal 2.0%, pair to pair less than or equal 4.0%
  • DC Resistance (Max.): less than or equal 9.38 Omega/100m
  • Dielectric Strength (Max.): DC 1000V 1min No Breakdown
  • Mutual Capacitance at Frequency: less than or equal 5.8nF/100m
  • NVP: 74%
  • Operating Frequency: 650MHz
  • Flame Test Method: IEC60332-1-2
  • Installation Temperature: -20 ~ +60 degrees Celsius
  • Operating Temperature: -40 ~ +75 degrees Celsius
  • Packaging: Reel in Box
  • 305m Cat6A blue S/FTP solid cable roll 650MHz
  • 100% bare copper cable
  • 23AWGx4P
  • LSZH jacket
  • AS/CA S008:2010 approved
  • 4K UHD ready
