CAT6A Shielded Cable, 305m, Pull Box with Reel, Grey
| Warehouse | Status |
|---|---|
| Fyshwick - ACT |
AVAILABLE TO ORDER
|
| Loganholme - QLD |
AVAILABLE TO ORDER
|
| Tulla Central Warehouse- VIC |
AVAILABLE TO ORDER
|
| Balcatta - WA |
AVAILABLE TO ORDER
|
The CAB-SCAT6AG-305 is a high-performance Cat6A S/FTP network cable designed for indoor installations where safety and speed are critical. This cable is well-suited for commercial and residential networks that demand reliable performance and enhanced fire safety.
Cable Type: S/FTP
Jacket Material: LSZH
Conductor Material: Bare Copper Cable
Insulation Material: Skin Foam Skin PE
Cable Length: 305m
Cable Weight: 16.8kg/305m
Cable Diameter: 0.56
Cable Gauge: 23AWG
Jacket Thickness: 0.55 plus or minus 0.05mm
DC Resistance Unbalanced (Max.): in pair less than or equal 2.0%, pair to pair less than or equal 4.0%
DC Resistance (Max.): less than or equal 9.38 Omega/100m
Dielectric Strength (Max.): DC 1000V 1min No Breakdown
Mutual Capacitance at Frequency: less than or equal 5.8nF/100m
NVP: 74%
Operating Frequency: 650MHz
Flame Test Method: IEC60332-1-2
Installation Temperature: -20 ~ +60 degrees Celsius
Operating Temperature: -40 ~ +75 degrees Celsius
Packaging: Reel in Box
- 305m Cat6A grey S/FTP solid cable roll 650MHz
- 100% bare copper cable
- 23AWGx4P
- LSZH jacket
- AS/CA S008:2010 approved
- 4K UHD ready
