Meanwell 13.8vDC 10.5A (151.55W) Single Output Power Supply with Backup Battery

CSD-AD-155A
AVAILABLE TO ORDER
Meanwell 13.8vDC 10.5A (151.55W) Single Output Power Supply with Backup Battery

The CSD-AD-155A is a 155-watt AC/DC power supply from MEAN WELL, designed for applications requiring both system power and battery backup. It's commonly used in security systems, UPS setups, and automation equipment.

  • Input Type: Single Phase
  • Input Voltage: 88 ~ 264VAC
  • Input Current: 1.5A / 230VAC
  • Output Voltage: 13.8V
  • Output Current: 10.5A
  • Rated Output Power: 151.55W
  • Output Type: Single
  • Output Voltage Adjustment: 12 ~ 14.5V
  • Charge output A: 0.5A
  • Auxiliary Power: N/A
  • Alarm Signals: N/A
  • Remote Functions: N/A
  • Dimming / Control Options: N/A
  • Temperature Compensation: N/A
  • Prescribed Electrical Item: No
  • SELV: Yes
  • Efficiency: 80.00%
  • Operating Temperature Range: -10 ~ +60 Degree C (Refer to "Derating Curve" in Data Sheet)
  • Warranty: 2 Years
  • Approvals: CE, CB, RCM
  • IP Rating / Environmental Protection: Less than IP65
  • Dimensions: 199x110x50mm (LxWxH)
  • Recommended for New Designs: Yes

  • Dual Outputs: 13.8V at 10.5A for system load and 13.3V at 0.5A for battery charging
  • Wide Input Range: Operates from 88-264VAC or 124-370VDC
  • Protections: Includes overload, overvoltage, and battery low protection
  • Compact Design: Enclosed metal casing suitable for industrial environments
