Meanwell 48vDC 2A (100 Watt) DIN Rail Industrial Power Supply

CSD-DR120A-48
AVAILABLE TO ORDER
Meanwell 48vDC 2A (100 Watt) DIN Rail Industrial Power Supply
Warehouse Status
Seven Hills - NSW
AVAILABLE TO ORDER
Waterloo - NSW
AVAILABLE TO ORDER
Loganholme - QLD
AVAILABLE TO ORDER
Dudley Park - SA
AVAILABLE TO ORDER
Tulla Central Warehouse- VIC
AVAILABLE TO ORDER
Balcatta - WA
AVAILABLE TO ORDER
Canning Vale - WA
AVAILABLE TO ORDER

The CSD-DR120A-48 is a 120W DIN rail-mounted DC-DC converter from MEAN WELL. It delivers a stable 48VDC output at 2.5A from a wide input range, with reinforced 4KVDC isolation and fanless design. Engineered for industrial and railway applications, it operates reliably across -40 Degree C to +70 Degree C and supports up to 150% peak load for demanding systems.

  • Input Voltage: 9 ~ 18VDC
  • 4:1 Wide Input: No
  • Input Current: 11.2A/12VDC
  • Output Voltage: 48VDC
  • Output Current: 0 ~ 2.1A
  • Rated Output Power: 100.8W
  • I/O Isolation (VDC): 4000VDC
  • Output Type: Single
  • Output Voltage Adjustment: 48 ~ 56V
  • Alarm Signals: N/A
  • Remote Functions: N/A
  • Prescribed Electrical Item: No
  • SELV: Yes
  • Efficiency: 88.50%
  • Operating Temperature Range: -40 ~ +70 Degree C (Refer to "Derating Curve in Data Sheet")
  • Warranty: 3 Years
  • Approvals: RCM, CE
  • IP Rating / Environmental Protection: Less than IP65
  • Dimensions: 32x125.2x102mm (WxHxD)
  • Recommended for New Designs: Yes

  • Input Voltage Range: 2:1 wide range (e.g., 9-18VDC, 16.8-33.6VDC, etc.)
  • Output: 48VDC at 2.1A
  • Peak Load: Supports 150% peak load capacity
  • Form Factor: Slim 32mm width for DIN rail mounting
  • Isolation: 4KVDC reinforced input/output isolation
  • Cooling: Fanless design for silent, reliable operation
