Meanwell 48vDC 2.5A (120 Watt) DIN Rail Industrial Power Supply
CSD-DR120B-48
AVAILABLE TO ORDER
Meanwell 48vDC 2.5A (120 Watt) DIN Rail Industrial Power Supply
The CSD-DR120B-48 is a 120W DIN rail-mounted DC-DC converter from MEAN WELL. It delivers a 48VDC output at up to 2.5A from a 16.8-33.6VDC input range. Designed for industrial and railway applications, it features reinforced 4KVDC isolation, fanless operation, and supports 150% peak load capacity. Its slim 32mm width makes it ideal for compact control panels and automation systems.
- Input Voltage: 16.8 ~ 33.6VDC
- 4:1 Wide Input: No
- Input Current: 5.6A/24VDC
- Output Voltage: 48VDC
- Output Current: 0 ~ 2.5A
- Rated Output Power: 120W
- I/O Isolation (VDC): 4000VDC
- Output Type: Single
- Output Voltage Adjustment: 48 ~ 56V
- Alarm Signals: N/A
- Remote Functions: N/A
- Prescribed Electrical Item: No
- SELV: Yes
- Efficiency: 91.00%
- Operating Temperature Range: -40 ~ +70 Degree C (Refer to "Derating Curve in Data Sheet")
- Warranty: 3 Years
- Approvals: RCM, CE
- IP Rating / Environmental Protection: Less than IP65
- Dimensions: 32x125.2x102mm (WxHxD)
- Recommended for New Designs: Yes
- Input Voltage Range: 16.8-33.6VDC
- Output Voltage: 48VDC at up to 2.5A
- Peak Load Capability: Supports 150% peak load for up to 1 second
- Efficiency: Up to 91%
- Mounting: DIN rail TS-35/7.5 or 15
- Form Factor: Slim 32mm width for space-constrained panels
- Cooling: Fanless design for silent and reliable operation
