Meanwell Industrial PSU, DIN Rail, 48V Output, 120W, to suit Industrial PoE Switch

CSD-EDR120-48
AVAILABLE TO ORDER
Meanwell Industrial PSU, DIN Rail, 48V Output, 120W, to suit Industrial PoE Switch
Warehouse Status
Seven Hills - NSW
AVAILABLE TO ORDER
Waterloo - NSW
AVAILABLE TO ORDER
Fyshwick - ACT
AVAILABLE TO ORDER
Loganholme - QLD
AVAILABLE TO ORDER
Dudley Park - SA
AVAILABLE TO ORDER
Tulla Central Warehouse- VIC
AVAILABLE TO ORDER
Mulgrave - VIC
AVAILABLE TO ORDER
Balcatta - WA
AVAILABLE TO ORDER
Canning Vale - WA
AVAILABLE TO ORDER

The CSD-EDR120-48 is a 120W DIN rail-mounted AC/DC power supply from MEAN WELL. It delivers a stable 48VDC output at 2.5A, with an adjustable voltage range via front potentiometer. Designed for industrial automation and control systems, it features a wide input range (90-264VAC), fanless cooling, and protection against short circuit, overload, and overvoltage. Its slim 40mm profile makes it ideal for compact installations.

  • Input Type: Single Phase
  • Input Voltage: 90 ~ 264VAC
  • Input Current: 1.3A / 230VAC
  • Output Voltage: 48V
  • Output Current: 2.5A
  • Rated Output Power: 120W
  • Output Type: Single
  • Output Voltage Adjustment: 48 ~ 55V
  • Output Current Adjustment Range: N/A
  • Current Sharing: N/A
  • Alarm Signals: N/A
  • Remote Functions: N/A
  • Dimming / Control Options: N/A
  • Control Options: N/A
  • Prescribed Electrical Item: No
  • SELV: Yes
  • Efficiency: 88.50%
  • Operating Temperature Range: -20 ~ +60 Degree C (Refer to "Derating Curve" in Data Sheet)
  • Warranty: 2 Years
  • Approvals: CE, CB, RCM
  • IP Rating / Environmental Protection: Less than IP65
  • Dimensions: 40x125.2x113.5mm (WxHxD)
  • Recommended for New Designs: Yes

  • Rated Output: 48VDC at 2.5A (120W total)
  • Voltage Adjustment: Output voltage adjustable via front potentiometer (+-10%)
  • Input Voltage Range: 90-264VAC or 127-370VDC
  • Frequency: 47-63Hz
  • Efficiency: Up to 88.5%
  • Mounting: DIN rail TS-35/7.5 or 15
  • Slim Profile: 40mm width for compact control panels
  • Cooling: Fanless, convection-cooled design
  • Protections: Short circuit, overload, overvoltage
