Meanwell 24vDC 4.5A (108W) Single Output Power Supply with PFC Function

CSD-HRP-100-24
AVAILABLE TO ORDER
Meanwell 24vDC 4.5A (108W) Single Output Power Supply with PFC Function
Warehouse Status
Fyshwick - ACT
AVAILABLE TO ORDER
Loganholme - QLD
AVAILABLE TO ORDER
Tulla Central Warehouse- VIC
AVAILABLE TO ORDER
Balcatta - WA
AVAILABLE TO ORDER

The CSD-HRP-100-24 is a high-reliability 100W enclosed AC/DC power supply from MEAN WELL. It delivers 24VDC at 4.5A and features active PFC, built-in remote ON/OFF control, and low no-load power consumption (<0.5W). With a wide input range (85-264VAC), 300VAC surge tolerance for 5 seconds, and compact 1U profile, it's ideal for industrial and OEM applications requiring efficient, space-saving power solutions.

  • Input Type: Single Phase
  • Input Voltage: 85 ~ 264VAC
  • Input Current: 0.6A / 230VAC
  • Output Voltage: 24V
  • Output Current: 4.5A
  • Rated Output Power: 108W
  • Output Type: Single
  • Output Voltage Adjustment: 22.8 ~ 28.8V
  • Output Current Adjustment Range: N/A
  • Auxiliary Power: N/A
  • Current Sharing: N/A
  • Alarm Signals: N/A
  • Remote Functions: Remote On / Off
  • Dimming / Control Options: N/A
  • Control Options: N/A
  • Prescribed Electrical Item: No
  • SELV: Yes
  • Efficiency: 88.50%
  • Operating Temperature Range: -40 ~ +60 Degree C (Refer to "Derating Curve" in Data Sheet)
  • Warranty: 5 Years
  • Approvals: CE, CB, RCM
  • IP Rating / Environmental Protection: Less than IP65
  • Dimensions: 159x97x38mm (LxWxH)
  • Recommended for New Designs: Yes

  • Rated Output: 24VDC at 4.5A (108W total)
  • Voltage Adjustment: Output voltage adjustable via built-in potentiometer
  • Remote ON/OFF Control: Built-in function for external switching
  • Input Voltage Range: 85-264VAC or 120-370VDC
  • Power Factor Correction: Active PFC function
  • Efficiency: Up to 88%
  • Form Factor: Compact 1U low-profile design
  • Cooling: Fanless, convection-cooled for silent operation
  • Protections: Short circuit, overload, overvoltage, overtemperature
  • Surge Tolerance: Withstands 300VAC input surge for 5 seconds
  • No-load Power Consumption: less than 0.5W for energy efficiency
