Meanwell 24vDC 2.5A (60W) Miniature DIN Rail Power Supply
CSD-MDR-60-24
AVAILABLE TO ORDER
Meanwell 24vDC 2.5A (60W) Miniature DIN Rail Power Supply
| Warehouse | Status |
|---|---|
| Loganholme - QLD |
AVAILABLE TO ORDER
|
| Tulla Central Warehouse- VIC |
AVAILABLE TO ORDER
|
| Mount Waverley - VIC |
AVAILABLE TO ORDER
|
| Balcatta - WA |
AVAILABLE TO ORDER
|
The CSD-MDR-60-24 is a compact 60W DIN rail-mounted AC/DC power supply that delivers a 24VDC output at 2.5A. Designed for industrial control systems and automation, it features a wide input range (85-264VAC), high efficiency (up to 88%), and low no-load power consumption (<0.75W). With protections against short circuit, overload, and overvoltage, plus a DC OK signal for remote monitoring, it's ideal for space-constrained, energy-efficient installations.
- Input Type: Single Phase
- Input Voltage: 85 ~ 264VAC
- Input Current: 1A / 230VAC
- Output Voltage: 24V
- Output Current: 2.5A
- Rated Output Power: 60W
- Output Type: Single
- Output Voltage Adjustment: 24 ~ 30V
- Output Current Adjustment Range: N/A
- Current Sharing: N/A
- Alarm Signals: DC OK
- Remote Functions: N/A
- Dimming / Control Options: N/A
- Control Options: N/A
- Prescribed Electrical Item: No
- SELV: Yes
- Efficiency: 88.00%
- Operating Temperature Range: -20 ~ +70 Degree C (Refer to "Derating Curve" in Data Sheet)
- Warranty: 3 Years
- Approvals: CE, CB, RCM
- IP Rating / Environmental Protection: Less than IP65
- Dimensions: 40x90x100mm (WxHxD)
- Recommended for New Designs: Yes
- Rated Output: 24VDC at 2.5A (60W total)
- Voltage Adjustment: Output voltage adjustable via front potentiometer (+-10%)
- Input Voltage Range: 85-264VAC or 120-370VDC
- Frequency: 47-63Hz
- Efficiency: Up to 88%
- No-load Power Consumption: less than 0.75W
- Mounting: DIN rail TS-35/7.5 or 15
- Slim Profile: Compact plastic housing for space-saving installations
- Cooling: Fanless, convection-cooled design
- Protections: Short circuit, overload, overvoltage
- DC OK Signal: LED indicator for output status
