Meanwell 48vDC 2.5A (120W) Single Output DIN Rail Power Supply

CSD-NDR-120-48
AVAILABLE TO ORDER
Meanwell 48vDC 2.5A (120W) Single Output DIN Rail Power Supply
Warehouse Status
Seven Hills - NSW
AVAILABLE TO ORDER
Waterloo - NSW
AVAILABLE TO ORDER
Fyshwick - ACT
AVAILABLE TO ORDER
Loganholme - QLD
AVAILABLE TO ORDER
Dudley Park - SA
AVAILABLE TO ORDER
Tulla Central Warehouse- VIC
AVAILABLE TO ORDER
Mount Waverley - VIC
AVAILABLE TO ORDER
Balcatta - WA
AVAILABLE TO ORDER
Canning Vale - WA
AVAILABLE TO ORDER

The CSD-NDR-120-48 is a slim 120W DIN rail-mounted AC/DC power supply designed for industrial applications. It delivers a stable 48VDC output at 2.5A and supports a wide input range of 90-264VAC or 127-370VDC. With high efficiency (up to 89%), built-in overload and overvoltage protection, and a compact 40mm-wide housing, it's ideal for space-constrained control panels and automation systems.

  • Input Type: Single Phase
  • Input Voltage: 90 ~ 264VAC
  • Input Current: 1.3A / 230VAC
  • Output Voltage: 48V
  • Output Current: 2.5A
  • Rated Output Power: 120W
  • Output Type: Single
  • Output Voltage Adjustment: 48 ~ 55V
  • Output Current Adjustment Range: N/A
  • Current Sharing: N/A
  • Alarm Signals: N/A
  • Remote Functions: N/A
  • Dimming / Control Options: N/A
  • Control Options: N/A
  • Prescribed Electrical Item: No
  • SELV: Yes
  • Efficiency: 89.00%
  • Operating Temperature Range: -20 ~ +70 Degree C (Refer to "Derating Curve" in Data Sheet)
  • Warranty: 3 Years
  • Approvals: CE, CB, RCM
  • IP Rating / Environmental Protection: Less than IP65
  • Dimensions: 40x125.2x113.5mm (WxHxD)
  • Recommended for New Designs: Yes

  • Rated Output: 48VDC at 2.5A (120W total)
  • Voltage Adjustment: Output voltage adjustable via front potentiometer (+-10%)
  • Input Voltage Range: 90-264VAC or 127-370VDC
  • Frequency: 47-63Hz
  • Efficiency: Up to 89%
  • Mounting: DIN rail TS-35/7.5 or 15
  • Slim Profile: 40mm width for compact control panels
  • Cooling: Fanless, convection-cooled design
  • Protections: Short circuit, overload, overvoltage
  • MTBF: Over 300,000 hours at full load, 25 Degree C ambient
