Meanwell 24VDC, 11.7A, Power Supply Replacement Unit for Honeywell BC200
| Warehouse | Status |
|---|---|
| Seven Hills - NSW |
AVAILABLE TO ORDER
|
| Loganholme - QLD |
AVAILABLE TO ORDER
|
| Tulla Central Warehouse- VIC |
AVAILABLE TO ORDER
|
The CSD-RSP-320-27 is a 320W enclosed AC/DC power supply designed for industrial and automation applications. It delivers a stable 27VDC output at 11.9A and supports a wide input range of 88-264VAC. Featuring active power factor correction (PFC), high efficiency, and built-in fan cooling with speed control, it ensures reliable performance up to 70 Degree C. With protections against short circuit, overload, overvoltage, and overtemperature, it's ideal for demanding environments.
- Input Type: Single Phase
- Input Voltage: 88 ~ 264VAC
- Input Current: 2A / 230VAC
- Output Voltage: 27V
- Output Current: 11.9A
- Rated Output Power: 321.3W
- Output Type: Single
- Output Voltage Adjustment: 26 ~ 31.5V
- Output Current Adjustment Range: N/A
- Auxiliary Power: N/A
- Current Sharing: N/A
- Alarm Signals: N/A
- Remote Functions: N/A
- Dimming / Control Options: N/A
- Control Options: N/A
- Prescribed Electrical Item: No
- SELV: Yes
- Efficiency: 89.00%
- Operating Temperature Range: -30 ~ +70 Degree C (Refer to "Derating Curve" in Data Sheet)
- Warranty: 3 Years
- Approvals: CE, CB, RCM
- IP Rating / Environmental Protection: Less than IP65
- Dimensions: 215x115x30mm (LxWxH)
- Recommended for New Designs: Yes
Rated Output: 27VDC at 11.9A (321.3W total)
Voltage Adjustment: Output voltage adjustable via built-in potentiometer
Remote ON/OFF Control: Supports external switching
LED Indicator: Displays power status
Input Voltage Range: 88-264VAC or 124-370VDC
Power Factor Correction: Active PFC function
Efficiency: Up to 89%
No-load Power Consumption: less than 0.5W
Form Factor: Compact 1U low-profile (30mm height)
Cooling: Built-in fan with speed control
Dimensions: 215 x 115 x 30 mm
Protections: Short circuit, overload, overvoltage, overtemperature
Surge Tolerance: Withstands 300VAC input surge for 5 seconds
Reliability: 100% full load burn-in test
