Meanwell 48vDC 5A (240 Watt) Single Output Industrial DIN Rail PS

CSD-SDR-240-48
AVAILABLE TO ORDER
Meanwell 48vDC 5A (240 Watt) Single Output Industrial DIN Rail PS
Warehouse Status
Seven Hills - NSW
AVAILABLE TO ORDER
Loganholme - QLD
AVAILABLE TO ORDER
Tulla Central Warehouse- VIC
AVAILABLE TO ORDER
Mulgrave - VIC
AVAILABLE TO ORDER
Balcatta - WA
AVAILABLE TO ORDER

The CSD-SDR-240-48 is a 240W DIN rail-mounted AC/DC power supply designed for industrial automation and control systems. It delivers a stable 48VDC output at 5A and supports a wide input range of 88-264VAC. Featuring high efficiency (up to 94%), active PFC, and built-in overload, overvoltage, and overtemperature protection, it ensures reliable performance in demanding environments. Its slim design and fanless cooling make it ideal for compact, noise-sensitive installations.

  • Input Type: Single Phase
  • Input Voltage: 88 ~ 264VAC
  • Input Current: 1.3A / 230VAC
  • Output Voltage: 48V
  • Output Current: 5A
  • Rated Output Power: 240W
  • Output Type: Single
  • Output Voltage Adjustment: 48 ~ 55V
  • Output Current Adjustment Range: N/A
  • Current Sharing: N/A
  • Alarm Signals: DC OK
  • Remote Functions: N/A
  • Dimming / Control Options: N/A
  • Control Options: N/A
  • Prescribed Electrical Item: No
  • SELV: Yes
  • Efficiency: 94.00%
  • Operating Temperature Range: -25 ~ +70 Degree C (Refer to "Derating Curve" in Data Sheet)
  • Warranty: 3 Years
  • Approvals: CE, CB, RCM
  • IP Rating / Environmental Protection: Less than IP65
  • Dimensions: 63x125.2x113.5mm (WxHxD)
  • Recommended for New Designs: Yes

  • Rated Output: 48VDC at 5A (240W total)
  • Voltage Adjustment: Adjustable output via front potentiometer
  • Peak Power Capability: Up to 150% of rated output for short durations
  • Input Voltage Range: 88-264VAC or 124-370VDC
  • Power Factor Correction: Built-in active PFC
  • Efficiency: Up to 94%
  • Mounting: DIN rail TS-35/7.5 or 15
  • Form Factor: Slim metal casing for enhanced heat dissipation and durability
  • Cooling: Fanless, convection-cooled design
  • Protections: Short circuit, overload, overvoltage, overtemperature
