The CSD-SPD-20-240P is a compact surge protection device rated for 240VAC systems, designed to safeguard electrical equipment from transient overvoltage's. It features a maximum discharge current of 20kA and a fast response time of less than 25ns. With IP67-rated housing, it's suitable for harsh environments and supports parallel wiring for easy installation. Ideal for LED drivers and industrial control systems, it complies with UL1449, EN61643-11, and other international safety standards.

• Operating Voltage: 240VAC, 50/60Hz
• Maximum Continuous Operating Voltage (MCOV): 300VAC
• Voltage Protection Rating (VPR): 1500V across L-FG, N-FG, and L-N
• Nominal Discharge Current: 5kA
• Maximum Surge Current: 20kA
• Response Time: Less than 25 nanoseconds
• Protection Modes: Line-to-ground, neutral-to-ground, and line-to-neutral
• Short Circuit Current Rating (SCCR): Tested with 30A class J fuse at 600VAC
• Connection Style: Parallel 3-wire connection
• LED Indicator: Shows operational status
• Enclosure Rating: IP67 for dust and moisture resistance
• Dimensions: 90 x 70 x 50 mm
