Dormakaba KES900S Electric Strike, Stainless Steel, 12/24V DC

DK-KES900S
AVAILABLE TO ORDER
Dormakaba KES900S Electric Strike, Stainless Steel, 12/24V DC
Warehouse Status
Seven Hills - NSW
AVAILABLE TO ORDER
Loganholme - QLD
AVAILABLE TO ORDER
Dudley Park - SA
AVAILABLE TO ORDER
Tulla Central Warehouse- VIC
AVAILABLE TO ORDER
Mulgrave - VIC
AVAILABLE TO ORDER
Balcatta - WA
AVAILABLE TO ORDER
Canning Vale - WA
AVAILABLE TO ORDER

The Dormakaba DK-KES900S Electric strike comes equipped with pre-load feature and is capable of opening when activated with up to 35kgs of pressure. Constructed of stainless-steel housing this lock offers a high level of security that can withstand up to 1000kgs of static force. It also offers dual voltage of 12VDC/24VDC and includes convenient fail safe/Fail secure functionality (changeable on site). The DK-KES900S also includes pre-drilled holes for optional extension lips and installation tabs for metal frames.

  • Dimensions: 175L x 44W x 27D(mm)
  • Holding strength: 680kg
  • Preload: 35kg
  • Operating voltage: 12/24VDC
  • Voltage tolerance: +/-15 percent
  • Current draw: 600mA/12VDC, 300mA/24VDC
  • Operating Temperature: -10 - +49 degrees Celsius
  • Humidity: 0 - 85 percent non-condensing
  • Cycle tested: to 1 million cycles
  • Material: Zinc alloy housing stainless steel keeper

  • Fail safe/fail-secure configurable
  • Monitored latch & lock status
  • Suits latch throw up to 18mm
  • Pre-drilled for optional extension lips
  • Includes mounting tabs for metal frame
  • Stainless steel construction (Fire-rated)
