Dynamix Cable, CAT6A, 305m, Pull Box with Reel, Blue

DYN-CAT6A-305
AVAILABLE TO ORDER
Dynamix Cable, CAT6A, 305m, Pull Box with Reel, Blue
Warehouse Status
Loganholme - QLD
AVAILABLE TO ORDER
Tulla Central Warehouse- VIC
AVAILABLE TO ORDER

The DYN-CAT6A-305 is a high-performance Cat6A U/FTP network cable designed for indoor data installations. Ideal for high-speed structured cabling in commercial and residential environments where safety and performance are key.

  • Cable Type: F/UTP
  • Jacket Material: LSZH
  • Conductor Material: Bare Copper Cable
  • Insulation Material: HDPE
  • Cable Length: 305m
  • Cable Weight: 16kg/305m
  • Cable Diameter: 0.57
  • Cable Gauge: 23AWG
  • Jacket Thickness: 0.55 plus or minus 0.05mm
  • DC Resistance Unbalanced (Max.): in pair less than or equal 2.0%, pair to pair less than or equal 4.0%
  • DC Resistance (Max.): less than or equal 9.38 Omega/100m
  • Dielectric Strength (Max.): DC 1000V 1min No Breakdown
  • Mutual Capacitance at Frequency: less than or equal 5.8nF/100m
  • NVP: 69%
  • Operating Frequency: 500MHz
  • Flame Test Method: IEC60332-1-2
  • Installation Temperature: -10 ~ +50 degrees Celsius
  • Operating Temperature: -20 ~ +75 degrees Celsius
  • Packaging: Reel in Box

  • 305m Cat6A blue F/UTP solid cable roll 500MHz
  • 100% bare copper cable
  • 23AWGx4P
  • LSZH jacket
  • AS/CA S008:2010 approved
