The Wide Body Low Profile Powered Enclosure is a locking general purpose ancillary enclosure. The Powered option incorporates a Battery-backed 3 Amp Smart Power Supply. (Note: Battery purchased separately) The enclosure can accommodate various combinations of Integriti Controllers, Modules and/or peripheral devices.

The 3A Smart Power Supply provided in the 'Powered' version can be used to power Integriti Modules and associated devices such as Detectors and Auxiliary Devices. It is a fully assembled, enclosed unit with a standard IEC power cord and does not require installers to be specially certified. It features a high reliability design that offers exceptional stability when used with the recommended battery type and is also compatible with Proximity type reader heads

• 3 amp smart power supply included
• Flexible mounting options for all Integriti PCBs
• Accommodates up to 2 x 18Ah batteries
• Tamper protected, key lockable
• Low profile metal enclosure: 595 (H) x 510 (W) x 90mm (D)

Datasheets

• IR-995204xx Datasheet.pdf
