Meanwell 15W DIN Rail DC to DC Isolated Converter
CSD-DDR-15G-5
AVAILABLE TO ORDER
Meanwell 15W DIN Rail DC to DC Isolated Converter
The CSD-DDR-15G-5 is a 15W DIN rail-mounted DC-DC converter from MEAN WELL. It delivers a stable 5VDC output at up to 3A from a wide 9-36VDC input range. Designed for industrial and railway use, it features reinforced 4KVDC isolation, compact 17.5mm width, and reliable operation across extreme temperatures (-40 degree C to +85 Degree C).
- Input Voltage: 9 ~ 36VDC
- 4:1 Wide Input: Yes
- Input Current: 0.8A / 24VDC
- Output Voltage: 5V
- Output Current: 0 ~ 3A
- Rated Output Power: 15W
- I/O Isolation (VDC): 4000VDC
- Output Type: Single
- Output Voltage Adjustment: 4.5 ~ 5.5V
- Alarm Signals: N/A
- Remote Functions: N/A
- Prescribed Electrical Item: No
- SELV: Yes
- Efficiency: 84.00%
- Operating Temperature Range: -40 ~ +85 Degree C (Refer to "Derating Curve in Data Sheet")
- Warranty: 3 Years
- Approvals: RCM, CE
- IP Rating / Environmental Protection: Less than IP65
- Dimensions: 17.5x90x54.5mm (WxHxD)
- Recommended for New Designs: Yes
- Input Voltage Range: 9-36VDC (4:1 wide range)
- Output Voltage: 5VDC at up to 3A
- Efficiency: Up to 84%
- Isolation Voltage: 4KVDC reinforced isolation between input and output
- Form Factor: Ultra-slim 17.5mm width for DIN rail mounting
- Cooling: Fanless design for silent operation
- Mounting: Standard DIN rail TS-35/7.5 or 15
