FSH FEM4300 Double Mag Lock, Hi-Vis Red-Green Bicolour LED, Monitored, 280kg, 12-24 VDC
FSH-FEM4300DM-HV
AVAILABLE TO ORDER
FSH FEM4300 Double Mag Lock, Hi-Vis Red-Green Bicolour LED, Monitored, 280kg, 12-24 VDC
| Warehouse | Status |
|---|---|
| Tulla Central Warehouse- VIC |
AVAILABLE TO ORDER
|
| Mulgrave - VIC |
AVAILABLE TO ORDER
|
| Balcatta - WA |
AVAILABLE TO ORDER
|
The FSH-FEM4300DM-HV is part of the FSH FEM4300 electromagnetic lock series and has a holding strength up to 280kg. Coming in different configurations such as single and double, monitored, and non-monitored and colours, including silver and black, makes this range suitable for almost any installation application. The series also includes a trigger input and a red/green LED indicator to represent locked and unlocked status, as well as an output that follows the door position status (on monitored models only). Accessories such as adjustable L & Z brackets for different mounting positions and armature plates for glass doors, further extend the installation capabilities.
- Dual Voltage: 12 /24 VDC field selectable
- Door and Lock Status Monitoring Sensor
- DSS and LSS S with "M" Models
- Built-in varistor (MOV) surge protection
- H-Vis Red-Green bicolour LED on monitored version (M-HV)
- No residual magnetism
- 5 year warranty
- Fire Rated (up to 2-hour fire rated in accordance with AS 1905.1:2015)
